Specification Sheet

Cash Acme 3/4″ F-82 Relief Valve with Lever Set at 30 PSI

The Cash Acme F-82 is a pressure-only ASME safety relief valve designed for use on hot water space heating boilers, water supply heaters and storage tanks.

The Cash Acme F-82 Safety Relief Valves are designed for use on hot water service only and are not to be used on steam. The Cash Acme F-82 is available in 3/4″, 1″, 1-1/4″, 1-1/2″ and 2″ sizes. All sizes have a female inlet and outlet. The 3/4″ size is also available with a male inlet.

The Cash Acme F-82 ASME Safety Relief Valves have a standard factory pressure relief setting from 30 to 150 psi. These high capacity pressure-only safety relief valves feature bronze bodies, silicone seat discs, EP diaphragms, brass internal parts, and stainless steel
pressure springs.

Features:

• Compact and economical:
  • Saves space and money!
• Completely automatic and reseats after pressure relief:
  • Ideal for most domestic water heater applications.
• ASME Section IV listed:
  • Rated for emergency steam discharge by the National Board of Boiler and Pressure Vessel Inspectors.
• Every valve is tested for performance prior to shipping:
  • Specify and install with confidence

Specification:

A high capacity safety relief valve shall be installed to relieve pressure at a pre-determined set. The valve shall have a bronze body with a silicone seat disc and stainless steel pressure spring. The valve shall be ASME listed and National Board Certified. The valve shall be a Cash Acme F-82.

PAZCA00135
