Garlock 37706-1104 – BLUE-GARD Fiber / Nitrile Binder Style 3000 Full Face Gasket – For 4″ Pipe

Features

• Color: Blue
• Compliances: REACH Compliant, RoHS Compliant
• Composition: Aramid Fiber with Nitrile Binder
• Fiber: Aramid
• Flange Standards/Pressure Class: ASME B16.5 Class 150
• Gasket Type: Ring
• Inside Diameter (Inch): 4.500
• Inside Diameter (mm): 114.30
• Max Temperature (C): 371
• Max Temperature (F): 700
• Min Temperature (C): -73
• Min Temperature (F): -100
• Nominal Pipe Size (inch): 4.000
• Nominal Pipe Size DN (mm): 100.0
• Nominal Pipe Size Fraction (Inch): 4
• Outside Diameter (inch): 6.875
• Outside Diameter (mm): 174.63
• Pipe Standard and Class: ASME B16.5 Class 150
• Pressure Max (bar): 70
• Pressure Max (psi): 1000
• Primary Dimensional Unit of Measure: Imperial
• Primary Nominal Thickness: 1/8 in
• Product Weight: 0.161 lbs
• Rubber Chemical Name: Acrylonitrile Butadiene
• Rubber Material: Nitrile
• Rubber Material Abbreviation: NBR
• Style/Model: Style 3000
• Temperature Range (C): -73 degrees C to 371 degrees C
• Temperature Range (F): -100 degrees F to 700 degrees F
• Thickness (inch): 0.125
• Thickness (mm): 3.18
