Taco VR1816 – Viridian High-Efficiency Variable Speed Circulator Pump – Cast Iron, Universal Flanged

The Taco VR1816-HY2-4C2A00 is a high-efficiency, variable-speed hydronic circulator pump with a wet rotor and durable cast iron body. Designed for closed-loop heating systems, this model is part of Tacos Viridian 00e series, delivering flexible performance with low energy use. It is not intended for potable water applications.

Specifications

• Flow rate: 0 to 16 gallons per minute (GPM)
• Maximum head: 18 feet
• Operating pressure (max): 125 pounds per square inch (psi)
• Operating temperature: Maximum 230F (110C), Minimum 36F (2C)
• Motor speed: 1,590 to 4,830 rotations per minute (RPM)
• Voltage: 120V, 60 Hz, single phase
• Horsepower: 1/25 HP
• Maximum amperage: 0.54 amps
• Power consumption: 4 to 44 watts

Features

• High-efficiency ECM motor: Uses up to 85% less electricity than traditional circulators
• Variable speed settings: Adjustable with three operation modes (infinitely variable fixed speed, constant pressure, proportional pressure)
• Operating mode presets: Six pressure presets simplify setup for different systems
• SureStart: Automatically unblocks the pump and purges air to prevent call-backs
• Built-in diagnostics: Five-color LED displays operating mode and diagnostic error codes
• Integral Flow Check (IFC): Included in carton, eliminating need for an external check valve
• BIO Barrier: Protects the pump from contaminants within the system
• Quiet operation: Engineered for whisper-quiet performance
• Universal flange: Fits pipe sizes from 3/4 to 1 1/2 inches for flexible installation
• Dual knockouts: Two electrical knockouts and 6-inch stranded wire leads for easy wiring
• Double insulated: No ground connection required

Applications

• Closed-loop hydronic heating systems
• Residential and light commercial circulation
• High-efficiency system upgrades requiring variable speed control
